MAXVU Temperature and Process Controller

MAXVU Temperature and Process ControllerMAXVU16 and MAXVU8

MAXVU has been designed to offer essential temperature control in a device that’s easy to install, fast to program and with improved display visibility.

MAXVU provides an affordable solution for applications where primary temperature control functions such as heat only or heat/cool are needed, it offers a universal input and up to 3 outputs with a choice of either relay or SSR.

Typical applications include packaging processes such as sealers and many more.

Read the Full Press Release

Key Features and Benefits of MAXVU

  • High visibility 18mm display digits (10.2mm lower display
  • Quick setup menu with top 10 configuration parameters
  • Thermocouple, PT100 or linear DC sensor input
  • Up to 3 outputs, relay or SSR
  • 2 process alarms, high/low, deviation or band.
  • 3 button operation
  • 2 x 4 digit display and 3 output status LEDs
  • Front panel configuration or via PC configuration software
  • RS485 Modbus RTU communications
Get a quote for  MAXVU

Set up in 60 Seconds - Watch the Video


MAXVU Applications

Get a quote for  MAXVU
MAXVU16 compact controller MAXVU8
Temperature and Process Controller Temperature and Process Controller
1/16th DIN 1/8th DIN
48 x 48mm 96 x 48mm
2 x 4 Large Digit LED 2 x 4 Large Digit LED
Visit the MAXVU16 Product Page Visit the MAXVU8 Product Page
